Road-constrained GPS
Pick a point or a route on OpenFreeMap. A* routing keeps the vehicle on roads, and the native service publishes a mock fix every 500–10000 ms.
mock location & virtual camera
Fake the fix.
Keep the test real.
Relocation is a developer test rig: a single Flutter shell over a native Kotlin mock-location service, plus a virtual camera that feeds your own app. Free maps, no API key, and nothing hidden behind a service you rent.
00:00:00
Relocation
MOCK · 1 Hz
Vehicle · Car
31.7295° N, 74.4163° E
Source · delivery_loop.mp4
mirror · loop · 1080p
Capture · GPS stamp
Pictures/Relocation
- Publish interval1000 ms
- Target speed48 km/h
- Map styleliberty
- Camera follow
MethodChannel · location
typed errors only
A rig you own,
not a service you rent.
Every part of the stack is inspectable: an open map style, a documented native service, and errors that come back as error codes.
App-private virtual camera
A bundled Camera1 module feeds a virtual stream to the app under test. It is scoped through LSPosed only where you choose to enable it.
Four tabs, one channel
Map, Virtual Camera, Cam and Settings. The Flutter UI never talks to Android directly — everything crosses a MethodChannel.
No map API key
OpenFreeMap styles — liberty, positon, dark — ship without a key, an account or usage limits.
Typed errors
PERMISSION_DENIED, MOCK_APP_NOT_SELECTED and LOCATION_UNAVAILABLE are real codes, not toast text.
Root optional
The core mock-location flow needs no root at all. Root lives inside a guest, only for the camera hook.
Everything you need,
four direct links.
The test rig itself, plus the three components used to build the verified guest environment described below.
Relocation
The test rig — mock GPS, virtual camera, GPS-stamped capture.
Open release
APK (.zip)
Virtual Master
Android clone that hosts the guest where root runs.
Open page
LSPosed
Zygisk module that scopes the camera hook per app.
Open release
Magisk
Root runtime and Zygisk, installed inside the guest.
Open release
Four tabs,
one native service.
A single Flutter shell over a native Kotlin mock-location service. The UI
never talks to Android directly — everything crosses a
MethodChannel that returns typed errors.
Interactive 3D map & GPS movement
The default screen. The camera centres on the real device fix, the vehicle marker sits on it, and a running session publishes a mock fix every 500–10000 ms (1 s by default).
- Five vehicles with per-vehicle speed limits and acceleration
- Hold LEFT/RIGHT and FWD/BACK; the first press auto-starts the session
- Destination by long-press, tap in pick-on-map mode, or typed lat/lon with
-90..90/-180..180validation - Camera follow with auto bearing; Recenter re-fetches the fix and re-centres
- Reset location in Settings snaps back to the real fix
Virtual camera simulator
Select an image or video, switch the source on, then capture a simulated photo. The internal simulator needs no root and no LSPatch.
- App-private media selection — the original file is never modified
- Loop video, mirror source, rotation correction, capture timestamp
- “Capture simulated photo” produces a JPEG labelled simulated, saved to
Pictures/Relocation - “Share capture” hands the generated file to any app you choose
- Target Applications list plus a Camera1 module test button
Cam — physical camera with a GPS stamp
The original mock-location and GPS-stamp camera path. Capture from the device camera with position and time overlaid, for delivery checks in the field.
- Stamp overlay rendered on the capture, not on the live preview only
- Mock and real fixes distinguished in the diagnostics panel
- Last successful internal capture and last error are surfaced in Diagnostics
Settings & permissions
Everything that governs a running session, plus a reusable setup guide you can follow without leaving the app.
- Publish interval (500–10000 ms) and a bounded target-speed slider
- Map style, camera follow, arrival notifications and toast toggle
- Permission management and the same guided setup accordion as onboarding
- Reset location returns the fix to the real position; a running session re-syncs in place
Setup in four steps
On a normal, non-rooted phone the core app needs no root at all.
-
1
Enable Developer Options
Settings → About phone → tap Build number seven times, then System → Developer options ON.
-
2
Select the mock location app
Developer options → Select mock location app → Relocation. The app shows a NOT SELECTED badge and an Open Developer Settings button until this is done.
-
3
Grant the permissions
Location, camera, storage on Android 8–9, and notifications on Android 13+. Each step is verified by Android and re-checked by the app.
-
4
Exempt battery optimisation
Battery settings → All apps → Relocation → Don’t optimise, so the foreground service is not killed while the app is in the background.
Run the whole rig
inside an Android clone.
Virtual Master gives you a disposable Android 9 guest where you can install a rooted runtime without touching the host phone.
Host and guest are different worlds
The physical phone is the host; the Virtual Master VM is the guest. The rules that matter:
- Relocation installed on the host and Relocation imported into the guest are two separate installations
- Permissions, selected media, target lists and settings are per installation
- The guest framework only affects processes inside that guest
- Your target camera app must live in the same guest — a guest Relocation cannot replace the host’s camera app
- Guest output is not automatically copied to the host Gallery; use the VM’s own export or share
Virtual Master APK setup
- 1
Install the Virtual Master APK
Install Virtual Master on the host phone and open it once so it can provision its runtime.
- 2
Create the guest
Create an Android 9 / API 28 arm64 guest. The verified configuration is Virtual Master 3.2.85 on an arm64 guest running ROM 1059.
- 3
Import Relocation
Use the VM import flow (Import → folder) to install the Relocation APK inside the guest, then complete onboarding inside the guest.
- 4
Import Magisk
Import the official Magisk release through Virtual Master’s own import UI. The VM exposes its own bundled Magisk runtime and adds a Magisk Enabled toggle in VM Settings.
- 5
Enable Zygisk and restart the VM
In the guest: Magisk → Settings → Zygisk ON. Then use the VM’s outer Restart VM — Restart, Reset, Repair, Restore and Delete VM are different operations.
- 6
Install LSPosed and set its scope
Install the LSPosed module from storage, enable Zygisk, then scope it to the camera target app only.
A manager icon being installed is not proof that the root runtime is active. Confirm Zygisk: Yes on the guest Magisk Home screen and check the runtime version in use.
Virtual Master
| Virtual Master | 3.2.85 |
|---|---|
| Guest OS | Android 9 / API 28, arm64, ROM 1059 |
| Guest Magisk runtime | 25200 (6066b5cf) |
| Working arrangement | physical phone → Virtual Master guest → Relocation + compatible framework + authorised Camera1 target |
Scope the camera hook
to the app you are testing.
Installed and enabled is not the same as scoped — and a scoped module is not the same as a verified capture.
Install it the supported way
- 1
Install as a Magisk module
Guest Magisk → Modules → Install from storage and pick the LSPosed archive. Follow the official LSPosed setup for the correct flavor.
- 2
Enable Zygisk and reboot
Zygisk must be on and the runtime must actually restart for the module to load.
- 3
Pick the scope
Open the LSPosed manager and select only the app under test. System Framework, Android System, System UI, Magisk and unrelated apps are not required for camera replacement.
- 4
Verify per target
For each target: preview appears, the JPEG callback arrives, and the file lands in the Gallery. These are three separate checks.
Root the guest,
not the phone.
Magisk provides the Zygisk runtime that LSPosed needs. In the tested setup the root runtime lives inside a Virtual Master guest, so the host phone is never unlocked, flashed or rooted.
Guest
Inside the guest
- Import the official Magisk release through Virtual Master’s own UI
- Confirm the runtime the guest actually uses — the VM ships its own bundled Magisk, and an imported APK’s version can differ from the VM runtime version
- Magisk → Settings → Zygisk ON, then verify Zygisk: Yes on Magisk Home
- Restart with the VM’s outer Restart VM; an in-guest reboot can leave the guest core process in a warning state
Host
Before you touch a physical phone
- Relocation never triggers a data wipe, and switching the module on or off is not a factory reset
- Unlocking a physical bootloader through Android’s documented flow can erase device data
- Do not treat “zero-wipe root guaranteed” as a fact; an unlocked device still carries firmware-specific risk
- This project’s own setup never unlocked, flashed or rooted the host bootloader
Official Magisk installation guide Android bootloader documentation
Questions that
come up first.
Answers reflect the current implementation. Menu labels and compatibility change with Android and OEM versions.
Do I need root for the core app?
No. Mock location and the internal virtual camera work on a normal non-rooted phone. Root is only involved when you want the embedded Camera1 module to reach other camera apps, which is the LSPosed / Magisk path described above.
How do I install the APK on a second device?
Copy build/app/outputs/flutter-apk/app-debug.apk to the target phone and open it with a file manager, allowing “Install unknown apps” for that installer only. Choose Update over an existing installation — do not uninstall or clear storage. The signing certificate must match: a debug key generated on another computer is not automatically the same key. If you see INSTALL_FAILED_UPDATE_INCOMPATIBLE or “App not installed”, check the package and signing key first; uninstalling is not the first solution.
Does the app bypass Android security?
No. Android requires you to explicitly select Relocation as the mock location app in Developer Options. ACCESS_MOCK_LOCATION is declared only so the app appears in that list; it is never granted automatically. Root, hidden-API and anti-spoofing tricks are deliberately not used.
What happens after a reboot or if the process is killed?
The simulation does not restart by itself. There is no reboot receiver. The app is a foreground service that keeps publishing while the app is backgrounded, and it re-syncs to the real fix when you reset the location in Settings.
Why does another camera app still show the real camera?
Because that path needs the framework, the scope and a verified target. “Module available” or “module ready” never means “active in every app”. Check three things separately for each target: the preview appears, the JPEG callback arrives, and the file is saved. On a standard non-rooted phone the current build cannot hand selected media to another ordinary camera app.
Does Virtual Master replace my host camera app?
No. A guest Relocation only affects processes inside the guest. The target camera app has to be installed in the same guest, and the guest framework only applies to that guest. Guest Gallery output is not automatically copied to the host Gallery.
Which Android versions are supported?
Relocation requires Android 8.0 / API 26 or newer. The experimental Camera2 backend is documented for Android 9 only and is default-off. The verified Virtual Master configuration is an Android 9 / API 28 arm64 guest. Compatibility with other ROMs, OEMs and Android versions has to be re-tested on each device.
Is the map service free?
Yes. The map uses OpenFreeMap styles with no API key, no usage limits and no account. Road data comes from OpenStreetMap via Overpass for the road graph and A* routing.
Can I use this on someone else’s phone or for anything that misleads people?
Only on devices you own or control, and only for testing your own software. Relocation is a test rig: it publishes a mock fix that Android visibly flags, and it is not intended to deceive third parties, evade location-based policy, or gain access to services you are not authorised to test.
Where do I find the full documentation?
In the repository under docs/: the complete setup and troubleshooting guide, the native camera API notes, the Camera2 compatibility and limits, the virtual camera module reference, and the executed verification results. Every device-specific limitation is recorded there rather than smoothed over.
Use it on devices you control
Relocation is a developer test rig. It publishes a mock location that Android flags in the system UI, and it never bypasses the platform’s own permission model. Use it on hardware you own or are authorised to test.
Take the rig
for a drive.
One APK, four tabs, and a map that costs nothing. Set it up in about five minutes.
